Gill 7014 Viscous Liquids Sensor

The 7014 Blackwater liquid level holding tank sensor has been designed for all applications where consistently reliable and maintenance-free measurement of Black and Grey water is needed. Tank profiling software provides compensation for irregular tank shapes and multiple output options, offering compatibility for the widest range of installations.

The Blackwater holding tank sensor has a probe element which goes into the tank and is robust and tough enough to tolerate the significant forces that are caused by sloshing of the contents in rough seas. The conductive level sensor measurement is a solid-state technology that does not have any moving parts.

The sensor consists of a smooth, non-stick probe without any holes for fluid flow in it, preventing being clogged or jammed by solids that can prevent operation. The sensor’s outputs have been configured so that it can be used with existing gauges and system display screens.

Features

• Resistive, Voltage and Current outputs available
• Marine grade stainless steel construction
• Reverse polarity protection
• Standard 1 1/4″ BSP male thread fitting
• Non-Stick FEP coating
• Continuous measurement
• Compensates for irregular tank shapes
• No holes to block
• No moving components

Custom lengths are available in all three outputs . Please phone for more information.
Tek Tanks would be pleased to offer a quotation for lengths up to 2000mm (MOQ applies)

The Gill 7014 sensors are all made to order. Please allow 3 weeks from date of order for manufacturing. Standard lead times do not apply to call off orders.
